The upper and lower wheels adjust the speed independently.
The upper blow air independently regulates the air volume and temperature.
The heater independently regulates the temperature.
Press foot pressure independent regulation.
More options on variety of accessories and devices for production requirement.
1. Plane, collage and part of three-dimensional technology.
2. Side bone collage.
3. Cylinder type collage, stick bales.
Film: Hot melt adhesive film
Feeding: Wheel up and down
Speed: 0-150mm/second
Presser foot: Cylinder push-pull type
Foot lift: 10mm
Comperssed air pressure: 0.5Mpa
Comperssed air consumption: 15-30L/min
Maximum Power: 3500W
Input power suply: Single phass 220V
Net weight：100kg
Gross weight: 160kg
Packing size: 133*66*138cm2
